	FLAGPOLES
	These gracefully tapered flagpoles have been manufactured to meet architectural standards for quality, strength and finish. Manufactured from high strength aluminum tubing, these flagpoles will enhance the landscape of commercial properties. Standard fittings for the Commercial line include a revolving cast aluminum double sheave truck; two sets of braided polypropylene halyards; four nickel plated swivel snap-hooks; two 9" cast aluminum cleats; heavy gauge, spun aluminum flash collar and a gold anodized, spun aluminum finial ball. The foundation sleeve is made of hot-dipped galvanized corrugated steel with integrated grounding rod. Contact EDWARDS for optional fittings and accessories. Most sizes of Commercial flagpoles are available with a heavy cast aluminum shoe-base mount for surface mounted applications. Many of the commercial shafts are available with heavy duty wall thickness for special applications. The standard shaft finish is a deep luster polished finish. Optional finishes include clear or Duranodic coloured anodized coating.
As the standard of the industry the Commercial line of ground set flagpoles offer strength, architectural beauty and a wide variety of sizes. Exposed heights range from 20' to 80' with shafts made from seamless high strength aluminum. On larger shafts where multiple sections are required, a self aligning internal sleeve is used. All sections are individually pre-fitted, matched and numbered at the factory Estate flagpoles are especially striking when installed in groups. Small business, apartment complexes, model homes and private residences are prime locations for the Estate tapered aluminum flagpole. Estate flagpoles are manufactured from the same high quality materials, and to the same standards, as the architecturally designed Continental Flagpoles.

	Sentry flagpoles offer the same quality and strength as the Continental flagpoles with the added feature of an internal halyard system. The internal halyard system provides added security for the flag and reduces halyard noise. The Sentry flagpole uses a standard halyard and cam cleat mounted inside the flagpole shaft. The simple to use cam cleat mechanism require no maintenance and is accessed by a locking cast aluminum door assembly. That door assembly is secured by 18-20 stainless steel allen head screws. Halyard noise is eliminated since only the flag, snap-hooks, counterweight and retainer ring are exposed. The standard shaft finish is a deep luster polished finish. Other architectural finishes are available to include, clear anodized, Duranodic bronze or black, or powdercoat paint finishes.
Standard fittings include a stationary cast aluminum truck on 5" shafts or a revolving cast aluminum truck assembly on 6" and 7" shafts; neoprene covered counterweight; beaded retainer ring; nickel plated snap-hooks; gold anodized aluminum finial ball and heavy gauge spun aluminum flash collar. The ground set foundation sleeve is made of hot-dipped galvanized corrugated steel with self-centering wedges and an integrated grounding rod. Contact EDWARDS for the many optional fittings available to customize the Sentry Flagpole.
REPRESENTATION ACROSS CANADA ~ SALES - INSTALLATION - SERVICE Please Contact us - for further information, specifications and architectural details.
